Features
Higher energy density for longer range and faster charging.
Maintenance-free, sealed LiFePO₄ cells.
Easy drop-in replacement for lead-acid batteries.
Long lifespan: up to 3,500+ cycles and 10-year design life.
Wide operating temperature range: −20 °C to 55 °C.
Lightweight design enables faster acceleration and less turf damage.
Smart BMS for safety and reliability.
Reduces total operating costs by up to 70–75% over 5 years.
Eco-friendly: no acid leaks, fumes, or gas emissions.
Specification
Model | Capacity | Voltage | Weight | W | D | H | Life | Downloads |
Ah | V | Kg | mm | mm | mm | Cycles | ||
FL24100 | 100 | 25.6 | 635 | 180 | 538.5 | 50 | 3500 | Download |
FL24150 | 150 | 25.6 | 635 | 180 | 538 | 90 | 3500 | Download |
FL24560 | 560 | 25.6 | 779 | 325 | 571 | 385 | 3500 | Download |
FL48420 | 420 | 51.2 | 970 | 630 | 571 | 300 | 3500 | Download |
FL48690 | 690 | 51.2 | 970 | 831 | 571 | 1450 | 3500 | Download |
FL80690 | 690 | 80.0 | 1009 | 832 | 749 | 1227 | 3500 | Download |
