Features
Floor standing design, easy to install, beautiful.
Adopt lithium iron phosphate batteries with safe and long life cycle.
Maximum charge/discharge up to 1C.
Friendly human-machine interface.
Compatible with multiple brands of inverters at the same time.
Application
Solar Energy Storage: Stores excess solar power generated during the day for use at night or during low-production periods, reducing grid reliance and electricity costs.
Peak/Off-Peak Tariff Optimization: Charges during low-tariff periods (e.g., nighttime) and discharges during high-tariff peaks, cutting electricity expenses by 20–30%.
Backup Power During Grid Outages: Provides emergency power for critical loads (e.g., refrigerators, medical devices) during grid failures, ensuring 4–6 hours of continuous operation.
Off-Grid Power Supply: Supports energy autonomy in remote areas without grid access, often integrated with solar/wind systems for 24/7 power.
Electric Vehicle (EV) Charging Support: Synergizes with rooftop solar to prioritize green energy for EV charging, lowering transportation energy costs.
Virtual Power Plant (VPP) Participation: Aggregates distributed household storage to provide grid-balancing services (e.g., frequency regulation) and generate user revenue.
Portable Power for Mobile Needs: Powers outdoor activities (e.g., camping, fieldwork) or temporary setups via lightweight, high-capacity mobile units.
Specification
Model | Capacity | Voltage | Weight | W | D | H | Max CH | Max DCH | Peak DCH | Life | Downloads |
Ah | V | Kg | mm | mm | mm | A | A | A | Cycles | ||
F15KWH | 280 | 51.2 | 130 | 530 | 168 | 981 | 200 | 200 | 250@500ms | 6000 | Download |
F51314 | 314 | 51.2 | 130 | 530 | 168 | 981 | 200 | 200 | 300@500ms | 6000 | Download |
F15KWH | 314 | 51.2 | 130 | 530 | 168 | 981 | 200 | 200 | 300@500ms | 6000 | Download |
F51314M | 314 | 51.2 | 130 | 530 | 168 | 981 | 100 | 100 | 150@500ms | 6000 | Download |
