Features
High energy density and lightweight design.
Long lifespan: up to 10 years and 3,500–5,000+ cycles.
Fast charging: fully charges in as little as 2.5 hours.
Maintenance-free: no watering, acid spills, or gas emissions.
Smart BMS: provides over-voltage, under-voltage, over-temperature, and short-circuit protection.
Wide temperature tolerance: operates from −20 °C to +55 °C.
Easy drop-in replacement for 36V, 48V, and 72V systems.
Reduces total operating costs by up to 70–75% over 5 years.
Environmentally friendly: non-toxic, recyclable LiFePO₄ chemistry.
Certified manufacturing and global after-sales support.
Specification
Model | Capacity | Voltage | Weight | W | D | H | Std CH | Std DCH | Max CH | Max DCH | Peak DCH | Life | Downloads |
Ah | V | Kg | mm | mm | mm | A | A | A | A | A | Cycles | ||
GC4880 | 80 | 51.2 | 50 | 440 | 310 | 230 | 50 | 130 | 55 | 250 | 300 | 3500 | Download |
GC36100 | 100 | 38.4 | 43 | 389 | 275 | 210 | 20 | 200 | 40 | 300 | 360 | 3500 | Download |
GC48100 | 100 | 51.2 | 43 | 460 | 334 | 247 | 50 | 100 | 100 | 200 | 300 | 3500 | Download |
GC48150 | 150 | 51.2 | 67 | 540 | 360 | 247 | 80 | 100 | 150 | 150 | 250 | 3500 | Download |
GC48105 | 105 | 51.2 | 43 | 460 | 334 | 247 | 100 | 200 | 100 | 250 | 375 | 3500 | Download |
GC72100 | 100 | 76.8 | 72 | 740 | 320 | 246 | 50 | 100 | 100 | 315 | 470 | 3500 | Download |
GC4865 | 65 | 51.2 | 40 | 433 | 278 | 244 | 50 | 130 | 55 | 195 | 293 | 3500 | Download |
